M30L40C-E3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 40V TO220AB
PDF
/
Inventory: 3348
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Technical
Packaging Tube
Published 2011
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 360μA @ 40V
Voltage - Forward (Vf) (Max) @ If 550mV @ 15A
Forward Current 30A
Max Reverse Leakage Current 360μA
Operating Temperature - Junction -65°C~150°C
Max Surge Current 280A
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 15A
Max Reverse Voltage (DC) 40V
Average Rectified Current 15A
Peak Reverse Current 360μA
Max Repetitive Reverse Voltage (Vrrm) 40V
Peak Non-Repetitive Surge Current 280A
Diode Configuration 1 Pair Common Cathode
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
