STTA2512P
RoHS
RoHS compliant
RoHS compliantPackage SOD-93-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 1200V 25A SOD93
PDF
/
Inventory: 9860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Recovery Time 110 ns
Diode Configuration 2 Independent
Reverse Voltage 1.2kV
Peak Reverse Current 150μA
Reverse Recovery Time 110 ns
Number of Phases 1
Average Rectified Current 25A
Max Reverse Voltage (DC) 1.2kV
Voltage - DC Reverse (Vr) (Max) 1200V
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Max Surge Current 210A
Operating Temperature - Junction 150°C Max
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 2.1V @ 25A
Output Current 25A
Power Dissipation 62.5W
Current - Reverse Leakage @ Vr 150μA @ 480V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T2
Reference Standard CECC
Pin Count 2
Base Part Number STTA251
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 25A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Rated DC 1.2kV
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series TURBOSWITCH?
Packaging Tube
Physical
Diode Element Material SILICON
Package / Case SOD-93-2
Mounting Type Through Hole
Mount Radial, Through Hole
