RB088T150FH
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 150V TO220F
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.311616
≥1 USD $1.311616
≥10 USD $1.237371
≥100 USD $1.167338
≥500 USD $1.101255
≥1000 USD $1.038916
Inventory: 1436
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 15μA
Diode Configuration 1 Pair Common Cathode
Non-rep Pk Forward Current-Max 50A
JEDEC-95 Code TO-220AB
Number of Phases 1
Average Rectified Current 5A
Max Reverse Voltage (DC) 150V
Application GENERAL PURPOSE
Output Current-Max 5A
Operating Temperature - Junction 150°C Max
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 880mV @ 5A
Current - Reverse Leakage @ Vr 15μA @ 150V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Series Automotive, AEC-Q101
Published 2016
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
