MBRB3030CTT4
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
SWITCHMODE? Tape & Reel (TR) Surface Mount Schottky Diode Array 540mV @ 15A 15A 30V -55C~175C
PDF
/
Inventory: 5553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series SWITCHMODE?
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish TIN LEAD
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status COMMERCIAL
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 600μA @ 30V
Voltage - Forward (Vf) (Max) @ If 540mV @ 15A
Operating Temperature - Junction -55°C~175°C
Output Current-Max 15A
Application POWER
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 15A
Number of Phases 1
Rep Pk Reverse Voltage-Max 30V
Non-rep Pk Forward Current-Max 200A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status Non-RoHS Compliant
