SBT80-10JS
RoHS
/
Package TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Bulk Through Hole Schottky 1Pair Common Cathode Diode Array 800mV @ 3A 8A 100V -55C~150C
PDF
/
Buying Options
Total Price: USD $2.19
Unit Price: USD $2.189738
≥1 USD $2.189738
≥10 USD $2.065789
≥100 USD $1.948856
≥500 USD $1.838545
≥1000 USD $1.734476
Inventory: 1137
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2006
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Copper/Silver/Nickel (Sn/Cu/Ag/Ni)
Additional Feature HIGH RELIABILITY, LOW NOISE
HTS Code 8541.10.00.80
Terminal Position SINGLE
Base Part Number SBT80-10
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 100μA @ 50V
Voltage - Forward (Vf) (Max) @ If 800mV @ 3A
Operating Temperature - Junction -55°C~150°C
Output Current-Max 4A
Application GENERAL PURPOSE
Max Reverse Voltage (DC) 100V
Average Rectified Current 8A
Number of Phases 1
JEDEC-95 Code TO-220AB
Non-rep Pk Forward Current-Max 60A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
