SB80W10T-H
RoHS
/
Package TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Bulk Through Hole Schottky 1Pair Common Cathode Diode Array 800mV @ 3A 8A 100V 150C
PDF
/
Inventory: 5946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Max Forward Surge Current (Ifsm) 40A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 40A
Max Repetitive Reverse Voltage (Vrrm) 100V
Number of Phases 1
Average Rectified Current 8A
Max Reverse Voltage (DC) 100V
Application GENERAL PURPOSE
Output Current-Max 4A
Max Surge Current 40A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 100μA
Forward Current 8A
Voltage - Forward (Vf) (Max) @ If 800mV @ 3A
Current - Reverse Leakage @ Vr 100μA @ 50V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Dual
Number of Elements 2
Pin Count 3
Terminal Position SINGLE
Subcategory Rectifier Diodes
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2006
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 3
Surface Mount NO
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Mounting Type Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Factory Lead Time 10 Weeks
