MMBD1705
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 1Pair Common Anode Diode Array 1.1V @ 50mA 50mA 350mW 700ps
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
Inventory: 41056
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 30V
Terminal Position DUAL
Terminal Form GULL WING
Current Rating 50mA
Number of Elements 2
Element Configuration Common Anode
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Standard
Current - Reverse Leakage @ Vr 50nA @ 20V
Power Dissipation 350mW
Voltage - Forward (Vf) (Max) @ If 1.1V @ 50mA
Operating Temperature - Junction 150°C Max
Max Surge Current 250mA
Output Current-Max 0.05A
Forward Voltage 1.1V
Max Reverse Voltage (DC) 30V
Average Rectified Current 50mA
Reverse Recovery Time 700 ps
Peak Reverse Current 50nA
Peak Non-Repetitive Surge Current 250mA
Reverse Voltage 30V
Diode Configuration 1 Pair Common Anode
Recovery Time 700 ps
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
