RB548WMFHTL
RoHS
RoHS compliant
RoHS compliantPackage SC-89, SOT-490
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
RB548WMFH IS THE HIGH RELIABILIT
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.2684
≥100 USD $0.160776
≥500 USD $0.148878
≥1000 USD $0.101235
Inventory: 1165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case SC-89, SOT-490
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Additional Feature HIGH RELIABILITY
Terminal Position DUAL
Terminal Form FLAT
JESD-30 Code R-PDSO-F3
Operating Temperature (Max) 150°C
Number of Elements 2
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 500nA @ 10V
Voltage - Forward (Vf) (Max) @ If 450mV @ 10mA
Operating Temperature - Junction 150°C Max
Output Current-Max 0.1A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 100mA
Number of Phases 1
Rep Pk Reverse Voltage-Max 30V
Non-rep Pk Forward Current-Max 0.5A
Diode Configuration 1 Pair Series Connection
Reverse Current-Max 0.5μA
Reverse Test Voltage 10V
Compliance
RoHS Status ROHS3 Compliant
