MBRF30H150CTG
RoHS
/
Package TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
SWITCHMODE? Tube Through Hole Schottky Diode Array 1.11V @ 15A 15A 150V -20C~150C
PDF
/
Buying Options
Total Price: USD $9.21
Unit Price: USD $9.21025
≥1 USD $9.21025
≥10 USD $7.55725
≥100 USD $7.3207
≥500 USD $7.0851
≥1000 USD $6.84855
Inventory: 1263
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
Published 2007
Series SWITCHMODE?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MBRF30H150CT
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 60μA @ 150V
Voltage - Forward (Vf) (Max) @ If 1.11V @ 15A
Case Connection ISOLATED
Operating Temperature - Junction -20°C~150°C
Output Current-Max 15A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 150V
Current - Average Rectified (Io) 15A
Number of Phases 1
Rep Pk Reverse Voltage-Max 150V
JEDEC-95 Code TO-220AB
Non-rep Pk Forward Current-Max 200A
Diode Configuration 1 Pair Common Cathode
