DCJ010-TL-E
RoHS
/
Package 3-SMD, Gull Wing
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 1Pair Series Connection Diode Array 1V @ 10mA 100mA 20V 125C Max
PDF
/
Buying Options
Total Price: USD $8.41
Unit Price: USD $8.4113
≥1 USD $8.4113
≥10 USD $6.90175
≥100 USD $6.6861
≥500 USD $6.47045
≥1000 USD $6.2548
Inventory: 3594
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Diode Configuration 1 Pair Series Connection
Average Rectified Current 100mA
Max Reverse Voltage (DC) 20V
Voltage - DC Reverse (Vr) (Max) 20V
Max Surge Current 300mA
Operating Temperature - Junction 125°C Max
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Current - Reverse Leakage @ Vr 100nA @ 15V
Diode Type Standard
Speed Small Signal =< 200mA (Io), Any Speed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1997
Packaging Tape & Reel (TR)
Physical
Number of Pins 3
Package / Case 3-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
