BAV70_S00Z
RoHS
/
Package SOT-563, SOT-666
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Small Signal Switching 70V 0.2A 3-Pin SOT-23 T/R
PDF
/
Inventory: 2655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case SOT-563, SOT-666
Technical
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 70V
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Operating Temperature - Junction 150°C Max
Voltage - DC Reverse (Vr) (Max) 70V
Current - Average Rectified (Io) 200mA
Reverse Recovery Time 6ns
Diode Configuration 1 Pair Common Cathode
