BAT54C_G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Schottky 1Pair Common Cathode Diode Array 800mV @ 100mA 200mA 0.25W 5ns
PDF
/
Inventory: 4138
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.10.00.70
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PDSO-G3
Qualification Status Not Qualified
Number of Elements 2
Power Dissipation-Max 0.25W
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 2μA @ 25V
Voltage - Forward (Vf) (Max) @ If 800mV @ 100mA
Operating Temperature - Junction -55°C~150°C
Output Current-Max 0.3A
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 200mA
Reverse Recovery Time 5ns
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status RoHS Compliant
