MDD72-16N1B
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 1.6KV 113A TO240AA
PDF
/
Buying Options
Total Price: USD $34.12
Unit Price: USD $34.1176
≥1 USD $34.1176
≥10 USD $30.31512
≥100 USD $26.51484
Inventory: 42
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Series Connection
Reverse Voltage 1.6kV
Non-rep Pk Forward Current-Max 1700A
Peak Non-Repetitive Surge Current 1.95kA
Number of Phases 1
Average Rectified Current 113A
Max Reverse Voltage (DC) 1.6kV
Forward Voltage 1.6V
Voltage - DC Reverse (Vr) (Max) 1600V
Application GENERAL PURPOSE
Output Current-Max 99A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.6V @ 300A
Current - Reverse Leakage @ Vr 15mA @ 1600V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Number of Elements 2
Qualification Status Not Qualified
Pin Count 3
Base Part Number MD*72
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-240AA
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 24 Weeks
