DSA90C200HB
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 200V TO247
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.9071
≥1 USD $5.9071
≥10 USD $4.8469
≥100 USD $4.6949
≥500 USD $4.54385
≥1000 USD $4.3928
≥3000 USD $3.93775
Inventory: 30905
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3 Full Pack
Number of Pins 3
Weight 6.500007g
Diode Element Material SILICON
Technical
Packaging Tube
Published 2006
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -55°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Pin Count 3
Number of Elements 2
Power Dissipation-Max 270W
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 900μA @ 200V
Voltage - Forward (Vf) (Max) @ If 960mV @ 45A
Forward Current 45A
Operating Temperature - Junction -55°C~175°C
Application SOFT RECOVERY
Forward Voltage 1.18V
Max Reverse Voltage (DC) 200V
Average Rectified Current 45A
Number of Phases 1
Peak Reverse Current 900μA
Max Repetitive Reverse Voltage (Vrrm) 200V
JEDEC-95 Code TO-247
Peak Non-Repetitive Surge Current 820A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 450A
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
