MBR40080CTR
RoHS
RoHS compliant
RoHS compliantPackage Twin Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers SI PWR SCHOTTKY 2TWR 20-100V 400A 80P56RV
PDF
/
Buying Options
Total Price: USD $215.94
Unit Price: USD $215.939228
≥1 USD $215.939228
≥200 USD $86.161688
≥480 USD $83.282499
≥1000 USD $81.859315
Inventory: 4020
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Physical
Mount Chassis Mount, Through Hole
Mounting Type Chassis Mount
Package / Case Twin Tower
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2012
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Solder
Max Operating Temperature 175°C
Min Operating Temperature -40°C
Pitch 4.2mm
Terminal Position UPPER
Orientation Straight
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PUFM-X2
Number of Contacts 12
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 5mA @ 20V
Voltage - Forward (Vf) (Max) @ If 840mV @ 200A
Max Voltage Rating (DC) 600.6kV
Forward Current 400A
Max Reverse Leakage Current 1μA
Max Surge Current 3kA
Output Current-Max 200A
Application POWER
Current - Average Rectified (Io) 400A DC
Max Reverse Voltage (DC) 80V
Average Rectified Current 400A
Number of Phases 1
Peak Reverse Current 1A
Max Repetitive Reverse Voltage (Vrrm) 80V
Diode Configuration 1 Pair Common Anode
Compliance
RoHS Status RoHS Compliant
