FST100200
RoHS
RoHS compliant
RoHS compliantPackage TO-249AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE SCHOTTKY 200V 50A TO249AB
PDF
/
Buying Options
Total Price: USD $143.45
Unit Price: USD $143.451393
≥1 USD $143.451393
≥200 USD $57.238501
≥480 USD $55.325606
≥1000 USD $54.380318
Inventory: 1283
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 5 months ago)
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case TO-249AB
Diode Element Material SILICON
Technical
Packaging Bulk
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.10.00.80
Terminal Position SINGLE
Terminal Form SOLDER LUG
JESD-30 Code R-PSFM-D3
Operating Temperature (Max) 150°C
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1mA @ 200V
Voltage - Forward (Vf) (Max) @ If 920mV @ 50A
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Application POWER
Max Reverse Voltage (DC) 200V
Average Rectified Current 50A
Number of Phases 1
Non-rep Pk Forward Current-Max 1000A
Diode Configuration 1 Pair Common Cathode
Reverse Current-Max 1000μA
Compliance
RoHS Status RoHS Compliant
