SBRT40V100CTE
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Full Pack, I2Pak
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE SBR TO262
PDF
/
Buying Options
Total Price: USD $10.04
Unit Price: USD $10.04055
≥1 USD $10.04055
≥10 USD $8.2384
≥100 USD $7.98095
≥500 USD $7.7235
≥1000 USD $7.46605
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 300μA
Diode Configuration 1 Pair Common Cathode
Non-rep Pk Forward Current-Max 180A
JEDEC-95 Code TO-262AA
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 100V
Application EFFICIENCY
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 730mV @ 20A
Current - Reverse Leakage @ Vr 300μA @ 100V
Diode Type Super Barrier
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e3
Published 2016
Packaging Tube
Physical
Diode Element Material SILICON
Package / Case TO-262-3 Full Pack, I2Pak
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
