SBR10100CT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
SBR? Tube Through Hole Super Barrier Diode Array 800mV @ 5A 5A 800mV 150C
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.358336
≥100 USD $0.26004
≥500 USD $0.217307
≥1000 USD $0.2035
Inventory: 97
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 6.000006g
Diode Element Material SILICON
Technical
Packaging Tube
Published 2012
Series SBR?
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Radial
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SBR10100CT
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Super Barrier
Current - Reverse Leakage @ Vr 100μA @ 100V
Voltage - Forward (Vf) (Max) @ If 800mV @ 5A
Forward Current 10A
Operating Temperature - Junction -65°C~150°C
Application FAST SOFT RECOVERY
Forward Voltage 800mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 5A
Number of Phases 1
Peak Reverse Current 100μA
Max Repetitive Reverse Voltage (Vrrm) 100V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 120A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 120A
Dimensions
Height 8.89mm
Length 10.4mm
Width 4.82mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
