B482F-2
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
RECTIFIER DIODE SERIES CONNECTED CENTER TAP 2ELEMENTS 3 UL RECOGNIZED Diode Array 600A 1.25V 125C
PDF
/
Inventory: 8632
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Diode Element Material SILICON
Number of Terminals 3
Technical
Terminal Finish COPPER
Additional Feature UL RECOGNIZED
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-XUFM-X3
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -40°C
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode Type RECTIFIER DIODE
Case Connection ISOLATED
Output Current-Max 35A
Application GENERAL PURPOSE
Number of Phases 1
Rep Pk Reverse Voltage-Max 1200V
Non-rep Pk Forward Current-Max 600A
Forward Voltage-Max 1.25V
Compliance
RoHS Status RoHS Compliant
