CDST-99-HF
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 70V 200MA SOT23
PDF
/
Inventory: 5676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Series Connection
Non-rep Pk Forward Current-Max 0.5A
Reverse Recovery Time 6ns
Average Rectified Current 200mA
Max Reverse Voltage (DC) 70V
Current - Average Rectified (Io) 200mA DC
Output Current-Max 0.2A
Operating Temperature - Junction 150°C Max
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Current - Reverse Leakage @ Vr 2.5μA @ 70V
Diode Type Standard
Speed Small Signal =< 200mA (Io), Any Speed
Power Dissipation-Max 0.225W
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-G3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.70
Additional Feature HIGH RELIABILITY
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
