CDBD20100-G
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Schottky 1Pair Common Cathode Diode Array 850mV @ 10A 20A 100V -55C~150C
PDF
/
Inventory: 8614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2013
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Additional Feature LOW POWER LOSS
HTS Code 8541.10.00.80
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSSO-G2
Operating Temperature (Max) 150°C
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 500μA @ 100V
Voltage - Forward (Vf) (Max) @ If 850mV @ 10A
Operating Temperature - Junction -55°C~150°C
Output Current-Max 10A
Application EFFICIENCY
Current - Average Rectified (Io) 20A DC
Max Reverse Voltage (DC) 100V
Average Rectified Current 20A
Number of Phases 1
Non-rep Pk Forward Current-Max 150A
Diode Configuration 1 Pair Common Cathode
Reverse Current-Max 500μA
Compliance
RoHS Status ROHS3 Compliant
