CMPD1001S TR
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
PDF
/
Buying Options
Total Price: USD $2
Unit Price: USD $1.99595
≥1 USD $1.99595
≥10 USD $1.6378
≥100 USD $1.5865
≥500 USD $1.5352
≥1000 USD $1.4839
Inventory: 18009
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Diode Element Material SILICON
Number of Terminals 3
Technical
JESD-609 Code e3
Pbfree Code icon-pbfree yes
Moisture Sensitivity Level (MSL) 1
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.70
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
JESD-30 Code R-PDSO-G3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Operating Temperature (Min) -65°C
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Power Dissipation-Max 0.35W
Diode Type RECTIFIER DIODE
Output Current-Max 0.25A
Rep Pk Reverse Voltage-Max 90V
Non-rep Pk Forward Current-Max 6A
Forward Voltage-Max 1.25V
Reverse Current-Max 0.1μA
Reverse Recovery Time-Max 0.05μs
Compliance
RoHS Status RoHS Compliant
