RoHS
/
Package MTK
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description BRIDGE RECT 3PHASE 1.4KV 55A MTK
PDF
/
Inventory: 7680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

DC Gate Trigger Current-Max 150mA
Repetitive Peak Off-state Voltage 1400V
Trigger Device Type SCR
Hold Current 200mA
Max Repetitive Reverse Voltage (Vrrm) 1.4kV
Average Rectified Current 55A
Case Connection ISOLATED
Diode Type Three Phase
Configuration 3 PHASE BRIDGE, HALF-CONTROLLED, COMMON CATHODE
Number of Elements 3
JESD-30 Code R-PUFM-X14
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
HTS Code 8541.30.00.80
Additional Feature UL APPROVED
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2008
Packaging Bulk
Operating Temperature -40°C~125°C TJ

Physical

Number of Pins 6
Package / Case MTK
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
