KBU8J
RoHS
/
Package 4-SIP, KBU
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Single Bridge Rectifier 1V @ 8A 8A 6.9W 1V
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.6016
≥1 USD $1.6016
≥10 USD $1.19592
≥100 USD $1.0648
≥500 USD $0.89408
≥1000 USD $0.7964
≥3000 USD $0.7304
Inventory: 1162
Minimum: 1
-
+
Technical Details
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBU
Number of Pins 4
Supplier Device Package KBU
Weight 9.00001g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2010
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 600V
Technology Standard
Current Rating 8A
Base Part Number KBU8J
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 10μA @ 600V
Power Dissipation 6.9W
Output Current 8A
Voltage - Forward (Vf) (Max) @ If 1V @ 8A
Forward Current 8A
Max Reverse Leakage Current 10μA
Max Surge Current 300A
Current - Average Rectified (Io) 8A
Forward Voltage 1V
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 300A
Voltage - Peak Reverse (Max) 600V
Dimensions
Height 19.3mm
Length 23.7mm
Width 7.1mm
