3N259
RoHS
/
Package 4-SIP, KBPM
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Tube Through Hole Single Phase Single Bridge Rectifier 1.1V @ 3.14A 2A 4.7W 1.1V
PDF
/
Inventory: 7117
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBPM
Number of Pins 4
Supplier Device Package KBPM
Weight 1.518004g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Capacitance 25pF
Voltage - Rated DC 1kV
Max Power Dissipation 4.7W
Technology Standard
Current Rating 2A
Base Part Number 3N259
Lead Pitch 4.1mm
Max Output Current 2A
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 1000V
Power Dissipation 4.7W
Output Current 2A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 3.14A
Forward Current 2A
Max Reverse Leakage Current 5μA
Max Surge Current 60A
Current - Average Rectified (Io) 2A
Forward Voltage 1.1V
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Non-Repetitive Surge Current 60A
Max Forward Surge Current (Ifsm) 60A
Voltage - Peak Reverse (Max) 1kV
Dimensions
Height 12.7mm
Length 15.24mm
Width 5.08mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
