RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE FAST RECOVERY 600V 0.8A D
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1596
≥1 USD $0.1596
≥10 USD $0.1311
≥100 USD $0.12635
≥500 USD $0.12255
≥1000 USD $0.11875
Inventory: 30006
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
Technical
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 20μA @ 600V
Voltage - Forward (Vf) (Max) @ If 1.32V @ 800mA
Operating Temperature - Junction -40°C~150°C
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 800mA
Reverse Recovery Time 80ns
Compliance
RoHS Status RoHS Compliant
Alternative Model
