GBL410-BPC01
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP, GBL
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
DIODE GPP SGL PHASE 4A GBL
PDF
/
Inventory: 6325
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Breakdown Voltage-Min 1000V
Voltage - Peak Reverse (Max) 1kV
Non-rep Pk Forward Current-Max 135A
Number of Phases 1
Current - Average Rectified (Io) 4A
Output Current-Max 3A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1V @ 2A
Current - Reverse Leakage @ Vr 5μA @ 1000V
Diode Type Single Phase
Configuration BRIDGE, 4 ELEMENTS
Number of Elements 4
JESD-30 Code R-PSIP-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology Standard
Additional Feature UL RECOGNIZED
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Operating Temperature -55°C~150°C
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case 4-SIP, GBL
Mounting Type Through Hole
