VUO125-18NO7
RoHS
RoHS compliant
RoHS compliantPackage PWS-C
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1.8KV 166A 5-Pin PWS-C
PDF
/
Buying Options
Total Price: USD $148.62
Unit Price: USD $148.624219
≥1 USD $148.624219
≥200 USD $59.30238
≥500 USD $57.321214
≥1000 USD $56.341791
Inventory: 9346
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 50mm
Length 67mm
Height 31mm
Technical
Voltage - Peak Reverse (Max) 1.8kV
Peak Non-Repetitive Surge Current 1.95kA
Number of Phases 3
Average Rectified Current 166A
Forward Voltage 1.3V
Max Surge Current 1.8kA
Max Reverse Leakage Current 300μA
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.07V @ 50A
Current - Reverse Leakage @ Vr 200μA @ 1800V
Diode Type Three Phase
Configuration BRIDGE, 6 ELEMENTS
Number of Elements 1
Qualification Status Not Qualified
Base Part Number VUO125
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
Additional Feature UL RECOGNIZED
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 5
Package / Case PWS-C
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 16 Weeks
