RFUH10NS6SFHTL
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
FAST RECOVERY DIODES (CORRESPOND
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.1176
≥1 USD $1.1176
≥10 USD $0.91696
≥100 USD $0.712976
≥500 USD $0.604349
Inventory: 1224
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 60A
Capacitance @ Vr, F 157pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 600V
Reverse Recovery Time 25ns
Forward Voltage 2.8V
Operating Temperature - Junction 150°C Max
Forward Current 10A
Voltage - Forward (Vf) (Max) @ If 2.8V @ 10A
Current - Reverse Leakage @ Vr 10μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Max Operating Temperature 150°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101
Packaging Cut Tape (CT)
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
