GBU2510-G
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP, GBU
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
BRIDGE RECT 1PHASE 1KV 25A GBU
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6544
≥1 USD $1.6544
≥10 USD $1.3772
≥100 USD $1.096216
≥500 USD $0.927573
≥1000 USD $0.787037
≥3000 USD $0.747683
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, GBU
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Technology Standard
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSFM-T4
Number of Elements 4
Configuration BRIDGE, 4 ELEMENTS
Diode Type Single Phase
Current - Reverse Leakage @ Vr 10μA @ 1000V
Voltage - Forward (Vf) (Max) @ If 1V @ 12.5A
Max Reverse Leakage Current 10μA
Max Surge Current 350A
Output Current-Max 25A
Current - Average Rectified (Io) 25A
Number of Phases 1
Voltage - Peak Reverse (Max) 1kV
Breakdown Voltage-Min 1000V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
