ISO7821FDWWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.551, 14.00mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.551 14.00mm Width) 2 1/1 General Purpose Digital Isolator 100kV/mus 5700Vrms 100Mbps -55C~125C
PDF
/
Buying Options
Total Price: USD $96.03
Unit Price: USD $96.03265
≥1 USD $96.03265
≥10 USD $92.93565
≥100 USD $89.8377
≥500 USD $80.54385
Inventory: 1002
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.45mm
Width 14mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 4.6ns
Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 100kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.4ns 2.4ns
Data Rate 100Mbps
Number of Channels 2
Voltage - Isolation 5700Vrms
Base Part Number ISO7821
Supply Voltage 2.5V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.551, 14.00mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
