ISO7820FDWWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.551, 14.00mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 5700VRMS 2CH GP 16SOIC
PDF
/
Inventory: 1410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.45mm
Width 14mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 4.6ns
Isolated Power No
Inputs - Side 1/Side 2 2/0
Common Mode Transient Immunity (Min) 100kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.4ns 2.4ns
Data Rate 100Mbps
Number of Channels 2
Voltage - Isolation 5700Vrms
Base Part Number ISO7820
Supply Voltage 2.5V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.551, 14.00mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 12 Weeks
