ISO7342CDW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
TEXAS INSTRUMENTS ISO7342CDWDigital Isolator, Quad, 4 Channel, 31 ns, 3 V, 5.5 V, WSOIC, 16 Pins
PDF
/
Buying Options
Total Price: USD $5.15
Unit Price: USD $5.148
≥1 USD $5.148
≥10 USD $4.6244
≥100 USD $4.37162
≥500 USD $3.78869
≥1000 USD $3.594395
≥3000 USD $3.225235
Inventory: 52
Minimum: 1
-
+
Technical Details
Technical
Rise / Fall Time (Typ) 2.1ns 1.7ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (PWD) 4 ns
Data Rate 25Mbps
Turn On Delay Time 31 ns
Propagation Delay 58 ns
Operating Supply Current 6.4mA
Number of Channels 4
Operating Supply Voltage 5V
Voltage - Isolation 3000Vrms
Base Part Number ISO7342
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Max Power Dissipation 111mW
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 665.986997mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 12 Weeks
