LTM2882CY-5
RoHS
RoHS compliant
RoHS compliantPackage 32-BBGA
Category Isolators / Digital Isolators
Description
DGT ISO 2500VRMS 4CH RS232 32BGA
PDF
/
Buying Options
Total Price: USD $24.83
Unit Price: USD $24.834816
≥1 USD $24.834816
≥238 USD $9.909769
≥476 USD $9.578918
≥952 USD $9.414806
Inventory: 1405
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 11.25mm
Length 15mm
Height Seated (Max) 3.62mm
Technical
Isolated Power Yes
Out Swing-Min 10 V
Inputs - Side 1/Side 2 2/2
Transmit Delay-Max 500 ns
Common Mode Transient Immunity (Min) 30kV/μs
Interface Standard EIA-232-F; TIA-232-F
Receiver Number of Bits 2
Channel Type Unidirectional
Driver Number of Bits 2
Rise / Fall Time (Typ) 60ns, 60ns
Input Characteristics SCHMITT TRIGGER
Differential Output NO
Data Rate 1Mbps
Supply Current-Max 21mA
Number of Channels 4
Power Supplies 5V
Voltage - Isolation 2500Vrms
Qualification Status Not Qualified
JESD-30 Code R-PBGA-B32
Pin Count 32
Base Part Number LTM2882
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 4.5V~5.5V
Technology Capacitive Coupling
Subcategory Line Driver or Receivers
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
Type RS232
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e1
Series μModule?
Published 2010
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 32-BBGA
Mounting Type Surface Mount
