ADUM241D0BRWZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
ANALOG DEVICES - ADUM241D0BRWZ - DIGITALER ISOLATOR 4KAN, 7.2NS, WSOIC-16
PDF
/
Buying Options
Total Price: USD $4.17
Unit Price: USD $4.1712
≥1 USD $4.1712
≥10 USD $3.7444
≥100 USD $3.539659
≥500 USD $3.067706
≥1000 USD $2.910362
≥3000 USD $2.61147
Inventory: 166
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 10.3mm
Height Seated (Max) 2.65mm
Technical
Pulse Width Distortion (PWD) 3 ns
Isolated Power No
Inputs - Side 1/Side 2 3/1
Common Mode Transient Immunity (Min) 75kV/μs
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns, 2.5ns
Data Rate 150Mbps
Propagation Delay 13 ns
Number of Channels 4
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 5.5V
Voltage - Isolation 5000Vrms
Pin Count 16
Base Part Number ADUM241
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology Magnetic Coupling
Terminal Finish Tin (Sn)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series iCoupler?
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
Alternative Model
