6N134/883B#300
RoHS
/
Package 16-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
High Speed Optocouplers 10MBd 2CH 1500Vdc Hermetically sealed
PDF
/
Buying Options
Total Price: USD $259.22
Unit Price: USD $259.220289
≥1 USD $259.220289
≥200 USD $103.430262
≥500 USD $99.974709
≥1000 USD $98.266626
Inventory: 9797
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SMD, Gull Wing
Number of Pins 16
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature HIGH RELIABILITY, OPEN COLLECTOR, TTL COMPATIBLE
HTS Code 8541.40.80.00
Subcategory Optocoupler - IC Outputs
Max Power Dissipation 200mW
Voltage - Supply 4.5V~5.5V
Supply Voltage 5V
Voltage - Isolation 1500VDC
Output Type Open Collector, Schottky Clamped
Max Output Current 25mA
Number of Elements 2
Number of Channels 2
Voltage - Forward (Vf) (Typ) 1.55V
Propagation Delay 100 ns
Input Type DC
Turn On Delay Time 140 ns
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Forward Current 20mA
Response Time 3.5e-8 ns
Data Rate 10MBd
Direction Unidirectional
Output Current per Channel 25mA
Rise Time 90ns
Fall Time (Typ) 40 ns
Rise / Fall Time (Typ) 35ns 35ns
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Common Mode Transient Immunity (Min) 1kV/μs
Inputs - Side 1/Side 2 2/0
Current Transfer Ratio 100 %
Hysteresis Ratio-Nom 0.0125
Compliance
RoHS Status Non-RoHS Compliant
