JSK5024S15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONV. 50W, 2:1 INPUT, 1X2
PDF
/
Buying Options
Total Price: USD $102.18
Unit Price: USD $102.184
≥1 USD $102.184
≥10 USD $96.4
≥100 USD $90.9434
≥500 USD $85.79566
Inventory: 7684
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 11mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Max Output Power 50W
Current - Output 1 3.33A
Control Features Enable, Active High
Output Power 50W
Voltage - Output 1 15V
Max Output Current 3.33A
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 92%
Number of Outputs 1
Depth 50.8mm
Max Power Dissipation 50W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 2.00Lx1.00W x 0.43 H 50.8mmx25.4mmx11.0mm
Series JSK50 (50W)
Published 2016
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
