JHL0324D15

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JHL0324D15 Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 2 Output, 20 V, 30 V, 3 W, 15 V
PDF
/
Buying Options
Total Price: USD $39.33
Unit Price: USD $39.326
≥1 USD $39.326
≥10 USD $37.1
≥100 USD $35
≥1000 USD $31.14988
≥3000 USD $29.38667
Inventory: 4721
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 10.16mm

Technical

Min Input Voltage (DC) 20V
Max Input Voltage (DC) 30V
Current - Output 2 100mA
Max Output Power 3W
Current - Output 1 100mA
Voltage - Output 2 -15V
Output Power 3W
Current - Output (Max) 100mA 100mA
Voltage - Output 1 15V
Max Output Current 100mA
Voltage - Isolation 4kV
Efficiency 87%
Number of Outputs 2
Depth 20.32mm
Max Power Dissipation 3W
Applications Medical
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JHL (3W)
Published 2015
Packaging Tube
Operating Temperature -20°C~80°C

Physical

Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 14 Weeks
