JCK4048S12
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCK4048S12 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 36 V, 75 V, 40 W, 12 V
PDF
/
Buying Options
Total Price: USD $70.79
Unit Price: USD $70.7868
≥1 USD $70.7868
≥10 USD $66.78
≥100 USD $63
≥500 USD $59.43396
≥1000 USD $56.06978
≥3000 USD $52.89601
Inventory: 4747
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 25.4mm
Height 10.16mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Nominal Output Voltage 12V
Max Output Power 40W
Current - Output 1 3.33A
Control Features Enable, Active High
Output Power 40W
Output Current 3.33A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Max Output Current 3.33A
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 91%
Number of Outputs 1
JESD-30 Code R-XDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 50.8mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 40W
Power Rating 40W
Additional Feature SEATED HGT-CALCULATED
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series JCK (40W)
Published 2011
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
