JCE0324D12-H

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCE0324D12-H Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 18 V, 36 V, 3 W, 12 V
PDF
/
Buying Options
Total Price: USD $28.09
Unit Price: USD $28.09
≥1 USD $28.09
≥10 USD $26.5
≥100 USD $25
≥500 USD $23.58491
≥1000 USD $22.24991
≥3000 USD $20.99048
Inventory: 2955
Minimum: 1
-
+

Technical Details

Technical

Max Input Voltage (DC) 36V
Min Input Voltage (DC) 18V
Current - Output 2 125mA
Max Output Power 3W
Current - Output 1 125mA
Voltage - Output 2 -12V
Output Power 3W
Current - Output (Max) 125mA 125mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Output 1 12V
Max Output Current 125mA
Output Voltage 12V
Voltage - Isolation 3kV
Efficiency 81%
Number of Outputs 2
JESD-30 Code R-PDMA-T8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 20.32mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JCE (3W)
Published 2014
Packaging Tube
Operating Temperature -40°C~100°C

Dimensions

Height 10.16mm
Length 31.75mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant

Physical

Package / Case 24-DIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
