ITV0512SA
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITV0512SA Isolated Board Mount DC/DC Converter, Fixed, 1 Output, 4.5 V, 5.5 V, 1 W, 12 V
PDF
/
Buying Options
Total Price: USD $8.48
Unit Price: USD $8.48
≥1 USD $8.48
≥10 USD $8
≥100 USD $7.54717
≥500 USD $7.11997
≥1000 USD $6.71695
≥3000 USD $6.33675
Inventory: 7880
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Max Output Power 1W
Current - Output 1 83.3mA
Output Power 1W
Voltage - Output 1 12V
Max Output Current 83.3mA
Voltage - Input (Max) 5.5V
Voltage - Isolation 3kV
Efficiency 80%
Number of Outputs 1
Depth 19.5mm
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.39 H 19.5mmx6.0mmx10.0mm
Series ITV (1W)
Published 2012
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
