ITQ2415SA
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V 6W
PDF
/
Buying Options
Total Price: USD $22.47
Unit Price: USD $22.472
≥1 USD $22.472
≥10 USD $21.2
≥100 USD $20
≥500 USD $18.86792
≥1000 USD $17.79993
≥3000 USD $16.79239
Inventory: 4160
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 9.2mm
Height 11.176mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 36V
Max Output Power 6W
Current - Output 1 400mA
Control Features Enable, Active Low
Output Power 6W
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Output 1 15V
Max Output Current 400mA
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 87%
Number of Outputs 1
JESD-30 Code R-XSMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ITQ (6W)
Published 2013
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 8-SIP Module, 6 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
