IMM0105S12
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONV, 1W, MEDICAL APPROVAL
PDF
/
Buying Options
Total Price: USD $12.92
Unit Price: USD $12.9214
≥1 USD $12.9214
≥10 USD $12.19
≥100 USD $11.5
≥500 USD $10.84906
≥1000 USD $10.23496
≥3000 USD $9.65562
Inventory: 4280
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Technical
Operating Temperature -20°C~100°C
Packaging Tube
Published 2016
Series IMM01 (1W)
Size / Dimension 0.77Lx0.36W x 0.44 H 19.5mmx9.2mmx11.1mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Isolated Module
Applications Medical
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 9.2mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-P6
Number of Outputs 1
Efficiency 81%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 9V
Output Voltage 12V
Max Output Current 83mA
Voltage - Output 1 12V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Power 1W
Control Features Enable, Active Low
Current - Output 1 83mA
Max Output Power 1W
Max Input Voltage (DC) 9V
Min Input Voltage (DC) 4.5V
Dimensions
Height 11.176mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
