IHL0205S3V3
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC, 2W, SINGLE OUTPUT, HIGH I
PDF
/
Buying Options
Total Price: USD $8.54
Unit Price: USD $8.53936
≥1 USD $8.53936
≥10 USD $8.056
≥100 USD $7.6
Inventory: 5297
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 9.398mm
Technical
Output Power 2W
Voltage - Input (Min) 4.5V
Voltage - Output 1 3.3V
Max Output Current 500mA
Voltage - Input (Max) 5.5V
Voltage - Isolation 5.2kV
Efficiency 76%
Number of Outputs 1
Max Power Dissipation 2W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.39W x 0.37 H 19.5mmx10.0mmx9.5mm
Series IHL02 (2W)
Published 2016
Packaging Tube
Operating Temperature -40°C~95°C
Physical
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
