AG01P-5
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
SINGLE O/P, DC-HV DC PCB MOUNT,
PDF
/
Buying Options
Total Price: USD $102.25
Unit Price: USD $102.2476
≥1 USD $102.2476
≥10 USD $96.46
≥100 USD $91
Inventory: 3381
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 6.35mm
Technical
Min Input Voltage (DC) 700mV
Max Input Voltage (DC) 5V
Max Output Power 1W
Current - Output 1 10mA
Output Power 1W
Voltage - Input (Min) 0.7V
Voltage - Output 1 100V
Max Output Current 10mA
Voltage - Input (Max) 5V
Voltage - Isolation 500V
Number of Outputs 1
Depth 23.37mm
Max Power Dissipation 1W
Applications ITE (Commercial)
Type High Voltage - Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Proportional Output
Size / Dimension 0.92Lx0.45W x 0.25 H 23.4mmx11.4mmx6.4mm
Series XP EMCO - AG (1W)
Published 2015
Packaging Box
Operating Temperature -25°C~75°C
Physical
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
Alternative Model
