VI-J6F-CX
RoHS
/
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 72V 75W
PDF
/
Inventory: 7778
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height 12.7mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 300V
Voltage - Input (Min) 200V
Voltage - Output 1 72V
Max Output Current 1.04A
Output Voltage 72V
Voltage - Input (Max) 400V
Voltage - Isolation 3kV
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-P9
Base Part Number VI-J6F
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 75W
Power (Watts) 75W
Applications ITE (Commercial)
Terminal Finish TIN LEAD OVER COPPER
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
Feature OCP, SCP
JESD-609 Code e0
Size / Dimension 2.28Lx2.40W x 0.50 H 57.9mmx70.0mmx12.7mm
Series VI-J00? (75W)
Published 2010
Packaging Bulk
Operating Temperature -25°C~100°C
Physical
Package / Case Half Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
