VE-JTX-EZ-S
RoHS
RoHS compliant
RoHS compliantPackage Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5.2V 25W
PDF
/
Inventory: 4162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Half Brick
Technical
Operating Temperature -10°C~100°C
Packaging Bulk
Published 2013
Series VE-J00? (25W)
Size / Dimension 2.28Lx1.80W x 0.52 H 57.9mmx45.7mmx13.2mm
JESD-609 Code e3
Feature OCP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish MATTE TIN OVER NICKEL
Applications ITE (Commercial)
Power (Watts) 25W
Max Power Dissipation 25W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VE-JTX
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 160V
Output Voltage 5.2V
Max Output Current 4.81A
Voltage - Output 1 5.2V
Voltage - Input (Min) 66V
Input Voltage-Nom 110V
Trim/Adjustable Output YES
Dimensions
Height 13.208mm
Compliance
RoHS Status ROHS3 Compliant
