V110C8M75BF3
RoHS
RoHS compliant
RoHS compliantPackage Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 8V 75W
PDF
/
Inventory: 1575
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 36.8mm
Length 57.9mm
Height 13.716mm
Technical
Protections OUTPUT OVER VOLTAGE
Input Voltage-Nom 110V
Voltage - Input (Min) 66V
Voltage - Output 1 8V
Max Output Current 9.38A
Output Voltage 8V
Voltage - Input (Max) 154V
Voltage - Isolation 3kV
Efficiency 84.3%
Approval Agency CE, TUV, UL
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PXMA-P7
Pin Count 7
Reach Compliance Code not_compliant
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 75W
Additional Feature SEATED HT CALCULATED
Power (Watts) 75W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OVP, UVLO
Size / Dimension 2.28Lx1.45W x 0.54 H 57.9mmx36.8mmx13.7mm
Series MICRO (75W)
Packaging Bulk
Operating Temperature -55°C~100°C
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
