THN 30-2423
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 30W
PDF
/
Buying Options
Total Price: USD $70.41
Unit Price: USD $70.4088
≥1 USD $70.4088
≥10 USD $66.68904
≥100 USD $64.572288
≥500 USD $61.396544
≥1000 USD $57.162248
≥3000 USD $52.404
Inventory: 105
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 10.4mm
Technical
Total Power Output-Max 30W
Voltage - Output 2 -15V
Current - Output (Max) 1A 1A
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 91%
Number of Outputs 2
JESD-30 Code S-MDMA-T6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OTP, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Series THN 30 (30W)
Published 2012
Operating Temperature -40°C~80°C With Derating
Physical
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
