TDR 2-1222WI
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 2W
PDF
/
Buying Options
Total Price: USD $29.72
Unit Price: USD $29.71922
≥1 USD $29.71922
≥10 USD $28.037
≥100 USD $26.45
≥500 USD $24.95283
≥1000 USD $23.54041
Inventory: 8226
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 14-DIP Module, 7 Leads
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Published 2007
Series TDR 2WI (2W)
Size / Dimension 0.74Lx0.50W x 0.34 H 18.9mmx12.8mmx8.7mm
JESD-609 Code e3
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Matte Tin (Sn) - annealed
Applications ITE (Commercial)
Power (Watts) 2W
Subcategory Other Analog ICs
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-G7
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 81%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 18V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 83mA 83mA
Voltage - Output 2 -12V
Total Power Output-Max 2W
Dimensions
Length 18.9mm
Compliance
RoHS Status ROHS3 Compliant
